Bearing Type | Ball |
Load Direction | Radial |
Construction | Single Row |
Seal Type | Sealed |
Model | 627 2rs |
Bore Dia (d) |
7mm |
Bore Dia Tolerance | -0.008mm to 0 |
Outer Dia (D) | 22mm |
Outer Dia Tolerance |
-0.008mm to 0 |
Width (B) |
7mm |
Width Tolerance | -0.12mm to 0 |
Ring Material | Gcr15 | 52100 Chrome Steel |
Ball Material | Gcr15 | 52100 Chrome Steel |
Cage Material | Gcr15 | 52100 Chrome Steel |
Shield Material | Gcr15 | 52100 Chrome Steel |
Dynamic Load Rating (Cr) (N) | 3300 |
Static Load Rating (Cor) (N) | 1370 |
Max Speed (Grease) (X1000 RPM) |
30 |
Max Speed (Oil) (X1000 RPM) | 36 |
Temperature Range |
-30℃ to 110 ℃ |
Precision Grade | P0 | ABEC-1 |
Radial Clearance Grade |
C0 |
Radial Clearance |
0.002mm to 0.013mm |
Weight |
13.1g |
|
